This 1,300 lb. heavy-duty cast iron planer offers rock solid rigidity and accurate planing for years to come. The hinged top allows easy access to the rollers and knives. The hood comes standard with a 5" dust port for easy attachment to any dust collection system. The cutterhead is complete with four high speed steel knives and turns at 4,800 rpm producing 19,200 cuts per minute. The anti-kick back fingers and pressure bar are located in close proximity to the cutterhead for an exceptional finish. The well designed infeed and outfeed rollers are fitted with roller bearings for long roller life. The sectional infeed and chip breaker are specially designed to allow multiple boards to be planed at the same time. The adjustable bed roller facilitates both rough and finish planing. The solid steel outfeed roller is machined with small serrations to insure a smooth finish yet provide positive feeding. The two-speed gearbox with machined detents is quickly changed up front when switching from rough to finish work. You may easily raise the massive ribbed cast iron, ground finished table 1 /16 with each turn of the hand wheel. The model 201 is available with a 7-1 /2 horsepower, 3-phase or single-phase motor. This planer is perfect for the small to medium shop with continuous planing requirements.

• Cast iron 1300 lb. construction for solid performance without vibration
• 2 feed speeds - 20/30 fpm - accommodates rough and fine finish work
• Segmented infeed roller with sectional chipbreaker allows multiple board planing
• 4-knife head offers 19,200 cuts per minute and widest capacity in its class
• Roller bearing-mounted feed rollers for long life
• Adjustable bed rollers allow smooth feeding of rough or finished workpieces
• Oversized cast iron table travels on 2 large lead screws for heavy duty support
• Standard Equipment:
• Dust collection chute with 5" port
• Adjustable foot pads

Range of Speeds
Motor Phase	1
Infeed Roller Diameter (In.)
Motor Current (Amps)
Knife Size (L x W x T)
Outfeed Table Length (In.)
Table Size with Extensions (L x W) (In.)
Type of Cutterhead
Number of Knives	4
Table Height from Floor (In.)
Table Support	2 Column
Maximum Planing Width (In.)	22
Maximum Height of Rollers Parallel to Tabletop (In.)
Cutterhead Diameter (In.)	3-1/4
Column Diameter (In.)
Movement - Horizontal (In.)
Segmented Infeed Roller Diameter (In.)	3
Recommended Circuit Size (Amps.)
Reversible
Digital Readout
Dust Collection Minimum CFM Required (CFM)	900
Maximum Planing Thickness (In.)	9-1/4
Table Size (L x W) (In.)	32-1/4 x 24
Minimum Planing Length (In.)	10
Dust Port Outside Diameter (In.)	5
Motor Power (HP)	7-1/2
Number of Speeds	2
Bed Rollers Adjustable from Front	2
Motor Voltage (V.)	230
Wiring Remarks
Cuts Per Minute	19,200
Maximum Full Width Depth of Cut (In.)
Maximum Depth of Cut (In.)	3/16
Movement - Vertical (In.)
Number of Rollers
Outfeed Roller Diameter (In.)	3
Cutterhead Speed (RPM)	4,800
Style (Type)	Planer
Feed Rate (FPM)	20, 30
Prewired Voltage (V.)
